GH3030 is an 80Ni-20Cr solid-solution nickel superalloy with good oxidation resistance and hot strength below 800 °C. Easy to hot/cold work and weld, it is a classic material for aero-engine combustors and afterburner components.
As a manufacturer and global exporter of special alloys since 2012, Shanghai Hangbo Alloy Group Co., Ltd. supplies GH3030 (ЭИ435) as round bars (φ2–600 mm, up to 12 m), plates & sheets (0.5–100 mm thick, up to 2500 mm wide), seamless tubes & pipes (φ6–630 mm OD, 0.5–40 mm wall), precision strip (0.02–3.0 mm, ±0.005 mm tolerance), welding wire & coils (1.0–5.0 mm) — all with EN 10204 3.1 certified material test reports.
GH3030 (ЭИ435) Chemical Composition (wt%)
| Element | Content (wt%) | Element | Content (wt%) |
|---|---|---|---|
| Ni (镍) | Balance | C (碳) | ≤ 0.12 |
| Cr (铬) | 19.0–22.0 | Mn (锰) | ≤ 0.70 |
| Fe (铁) | ≤ 1.5 | Si (硅) | ≤ 0.80 |
| Ti (钛) | 0.15–0.35 | S (硫) | ≤ 0.020 |
| Al (铝) | ≤ 0.15 |
GH3030 (ЭИ435) Mechanical Properties
| Property | Value |
|---|---|
| Tensile strength (Rm) | ≥ 685 MPa |
| Yield strength (Rp0.2) | ≥ 295 MPa |
| Elongation (A) | ≥ 30 % |
| Hardness | ≤ 190 HB |
| Density | 8.40 g/cm³ |
| Melting range | 1374–1420 °C |
| Thermal conductivity | 15.1 W/m·K |
| Young's modulus | 212 GPa |
| Max service temperature | 1000 °C |
Key Advantages
- Oxidation resistant to about 1000 °C with good hot strength below 800 °C
- Solid-solution strengthened — stable structure, resistant to age embrittlement
- Excellent weldability with matching filler
- Good hot and cold formability for sheet stampings
Relevant Standards
- GB/T 14992
- GB/T 14994
- GJB 3165
Typical Applications
- Aero-engine combustors, afterburners and flame tubes
- Turbine guide vanes operating below 800 °C
- Industrial gas turbine hot parts
- Heat-treat furnace components
Why Buy from Hangbo Alloy?
- Factory-direct manufacturer — founded 2012, headquartered in Shanghai Qingpu
- Full product range — bar, plate, sheet, strip, tube, forging, welding wire, flanges and machined parts
- Certified quality — ISO 9001:2015, GB/T 19001-2016, GJB 9001C-2017, EN 10204 3.1 mill test certificates with third-party inspection (SGS / BV / TUV) available on request
- Complete mill documentation — chemical analysis, mechanical test, ultrasonic test (UT), hardness and grain-size reports with every shipment
Contact Us — Shanghai Hangbo Alloy Group Co., Ltd.
Shanghai Hangbo Alloy Group Co., Ltd.
📍 No. 388 Songhuang Road, Qingpu District, Shanghai, China
📞 Tel / WhatsApp: +86 15618279078
✉️ Email: demi@nickel-alloy.com
🕒 Available 24 hours a day, 7 days a week — enquiries answered around the clock.
Send your drawing or enquiry (grade, form, size, quantity, standard) for a same-day quotation.
Frequently asked questions
What heat treatment does GH3030 use?
GH3030 is normally solution treated at 980–1020 °C and air or water cooled. For cold-rolled sheet, annealing at 1050–1080 °C gives a fine grain and good formability. The alloy cannot be age hardened — properties are adjusted only by solution treatment and cold work.
What forms and sizes are available?
We supply GH3030 (ЭИ435) as round bars (φ2–600 mm, up to 12 m), plates & sheets (0.5–100 mm thick, up to 2500 mm wide), seamless tubes & pipes (φ6–630 mm OD, 0.5–40 mm wall), precision strip (0.02–3.0 mm, ±0.005 mm tolerance), welding wire & coils (1.0–5.0 mm). Custom lengths, tolerances and machining to drawing are available on request.
What is the MOQ and lead time?
MOQ is flexible — trial orders from a single piece are welcome. Stock sizes ship in 3–7 days; custom forgings and machined parts typically 15–35 days depending on quantity and process.
Can you provide third-party inspection and shipping to my port?
Yes. SGS / BV / TUV or your nominated inspector can witness all tests before shipment. Full export documentation is provided, and we ship worldwide by sea or air on FOB, CIF or DDP terms.
