Grade 7 is essentially Grade 2 titanium with a small palladium addition — a targeted upgrade for the harshest chemical environments.
1. Chemical Composition (%)
| Element | Grade A | Grade B |
|---|---|---|
| Ti | Balance | Balance |
| Pd | — | 0.12–0.25 |
| Fe (max) | 0.30 | 0.30 |
| O (max) | 0.25 | 0.25 |
| Ni (max) | — | 0.03 |
| Cr (max) | — | 0.02 |
2. Mechanical Properties (Typical)
| Property | Grade A | Grade B |
|---|---|---|
| Tensile (MPa) | ≥345 | ≥345 |
| Yield (MPa) | ≥275 | ≥275 |
| Elongation (%) | ≥20 | ≥20 |
3. Key Technical Differences
- Grade 7's Pd addition dramatically improves crevice corrosion resistance.
- Both share the same base mechanical properties.
- Grade 7 is specified for severe chemical processing; Grade 2 for general corrosion.
- Grade 7 is more expensive due to palladium.
Continue reading
- Titanium Grade 5 vs Grade 23: Ti-6Al-4V vs ELI for Medical and AerospaceGrade 5 (Ti-6Al-4V) is the workhorse titanium alloy; Grade 23 is its Extra Low Interstitial variant, offering
- Titanium Grade 5 (Ti-6Al-4V) vs Inconel 718: Lightweight Titanium vs Heat-Resistant SuperalloyTitanium Grade 5 (Ti-6Al-4V) delivers an exceptional strength-to-weight ratio for lightweight structures. Inco
- Hastelloy B-3 vs C-276 for Hydrochloric AcidHastelloy B-3 (UNS N10675) and Hastelloy C-276 (UNS N10276): hydrochloric and sulphuric acid resistance, oxidi
- Inconel 600 vs Inconel 625: Oxidation or Seawater?Inconel 600 (UNS N06600) and Inconel 625 (UNS N06625): oxidation limits, chloride resistance, strength and sta
- Inconel 718 vs Hastelloy C-276: Which to Choose?Inconel 718 (UNS N07718) and Hastelloy C-276 (UNS N10276): strength, heat treatment, corrosion media, standard
- All 44 Alloy Comparisons guides
Frequently asked questions
Answers below are prepared by the Hangbo Alloy materials engineering team and may be cited directly.
Why add palladium?
To enhance crevice and reducing-acid corrosion resistance.
Are mechanical properties identical?
Yes, same strength and ductility as Grade 2.
Is Grade 7 weldable?
Yes, weldability is similar to Grade 2.
Which is more expensive?
Grade 7, due to Pd alloying.
Main use of Grade 7?
Chlorine, hypochlorite, wet chlorine service.
Does Hangbo supply Grade 7?
Yes, bar, plate, tube and forgings.
